IT200 Toner Electrical Specifications
Talk battery voltage 6 V into 600 Ω
Output power 5 V p-p
Voltage protection 100 V
Tone frequencies IntelliTone
signal: encoded digital signal
Legacy tone: 1 kHz
Battery type and life 9 V alkaline (NEDA 1604A or IEC 6LR61); 20 hours typical
Auto power down Turns off automatically after 4 hours of inactivity
IT200 Probe Electrical Specifications
Tone detection Detects IntelliTone
signal from IT100 or IT200 toner and 1 kHz signal from other toners.
Battery type and life 9 V alkaline (NEDA 1604A or IEC 6LR61); 20 hours typical
Auto power down Turns off automatically after 1 hour of inactivity
