- 95 - Unique Features
EZ Smart Connect
A. System Requirements
1. Intel
®
Smart Connect Technology enabled in BIOS Setup
2. Windows 7 with SP1/Windows 8/Windows 8.1
3. Intel
®
Smart Connect Technology utility installed
4. Properly-working network connection
5. Programs added to the White List must be turned on
(Note)
B. Using EZ Smart Connect
Select EZ Smart Connect. Under File Name, select the apps to be auto-updated by Smart Connect. Double-
click the app to add it to the Application permission list.(Double-click toreturntothepreviousdirectory.)
(Note) ThisfeatureworksbestwithprogramsdesignedtoworkautomaticallywiththeInternettoobtaintheir
data such as Outlook
®
, Windows Live
™
Mail, and Seesmic
®
.
