- 6 -
Box Contents
5 GA-Z97X-Gaming G1 WIFI-BK motherboard
5 Motherboard driver disk
5 User's Manual
5 Quick Installation Guide
5 Six SATA cables
5 I/O Shield
5 One 2-Way SLI bridge connector
5 One 3-Way SLI bridge connector
5 One 4-Way SLI bridge connector
5 One 2-Way CrossFire bridge connector
5 3.5" Front Panel with 2 USB 3.0/2.0 ports
5 OneGC-WB867D-I(includingoneantenna,oneUSB2.0cable,driverdisk,
anduser'smanual)
Optional Items
2-portUSB2.0bracket(PartNo.12CR1-1UB030-6*R)
eSATAbracket(PartNo.12CF1-3SATPW-4*R)
3.5"FrontPanelwith2USB3.0/2.0ports(PartNo.12CR1-FPX582-2*R)
HDMI-to-DVIadapter(PartNo.12CT2-HDMI01-1*R)
The box contents above are for reference only and the actual items shall depend on the product package you
obtain. The box contents are subject to change without notice.
