Extraordinary maintenance

7. Extraordinary maintenance

The oven will on occasion need minor maintenance or replacement of parts subject to

wear. Specific instructions for each of these procedures appears below.

Before any intervention, disconnect the power supply of the device.

7.1 Replacement of oven light bulbs

Remove upper oven protection A and ring B as well as the glass cover C, unscrewing

it anticlockwise. Replace light bulb D. Reassemble ring B, cover C and upper

protection A.

The standard bulbs are halogen: do not touch them directly with your fingers.

Use insulation to protect your hand.

Use only bulbs that are available at authorised service centres.

7.2 Cleaning of hot air fan

The fan has to be cleaned at regular

intervals. Remove the rear deflector by

unscrewing nuts E. With your hand keep the

blades stopped and, using a coin, loosen the

central ring nut F, rotating clockwise.

In this way, it is easier to remove any

cooking residues, preventing them from

burning the next time the oven is used.

After having cleaned the fan, reassemble it

and the rear deflector, proceeding in the

opposite order with respect to the

disassembly instructions.
