GA-N3050N-D2P Motherboard Layout
The box contents above are for reference only and the actual items shall depend on the product package you obtain.
The box contents are subject to change without notice.
Box Contents
5 GA-N3050N-D2P motherboard
5 Motherboard driver disk 5 Two SATA cables
5 User's Manual 5 I/O Shield
HDMI
CPU_FAN
SYS_FAN
Intel
®
Braswell SoC N3050
ATX
GA-N3050N-D2P
F_AUDIO
AUDIO
DDR3_1
DDR3_2
BAT
ATX_12V
COMA
R_USB30
CODEC
CLR_CMOS
M_BIOS
VGA
LPT
USB30_LAN
PCI
CI
COMB
iTE
®
Super I/O
Realtek
®
GbE LAN
F_USB1
SPEAKER
F_USB2
F_PANEL
Genesys Logic
USB 2.0 Hub
PCIe to PCI
Bridge
SATA3
0 1
