- 17 -
2-2 Advanced
& OnBoard LAN Controller (LAN1)
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled.
& OnBoard LAN Controller#2 (LAN2)
Enables or disables the onboard LAN function. (Default: Enabled)
If you wish to install a 3rd party add-in network card instead of using the onboard LAN, set this item to
Disabled.
& Power Loading
Enables or disables dummy load. When the power supply is at low load, a self-protection will activate causing
it to shutdown or fail. If this occurs, please set to Enabled. AutoletstheBIOSautomaticallycongurethis
setting. (Default: Auto)
& Max TOLUD
AllowsyoutocongurethemaximumTOLUDvalue.2GBisthedefault.
& Restore AC Power Loss
Determines the state of the system after the return of power from an AC power loss.
Power Off The system stays off upon the return of the AC power. (Default)
Power On The system is turned on upon the return of the AC power.
Last State The system returns to its last known awake state upon the return of the AC power.
& Soft-Off by PWR-BTTN
ConguresthewaytoturnoffthecomputerinMS-DOSmodeusingthepowerbutton.
Instant-Off Press the power button and then the system will be turned off instantly. (Default)
Delay 4 Sec. Press and hold the power button for 4 seconds to turn off the system. If the power
button is pressed for less than 4 seconds, the system will enter suspend mode.
& DDR Voltage Control
Allows you to set the memory voltage. Options are: 1.35V, 1.50V, Auto. Auto lets the BIOS automatically
congurethissetting.(Default:Auto)
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main
OnBoard LAN Controller [Enabled]
OnBoard LAN Controller#2 [Enabled]
Power Loading [Auto]
Max TOLUD [2 GB]
Restore AC Power Loss [Power Off]
Soft-Off by PWR-BTTN [Instant-off]
DDR Voltage Control [Auto]
` Realtek PCIe GBE Family Controller (MAC:40:8D:5C:16:98:54)
` Realtek PCIe GBE Family Controller (MAC:40:8D:5C:16:98:55)
` Hardware Monitor
` SIO Misc Functions
` CPUConguration
` IntelIGDConguration
` SATAConguration
` SIOConguration
` NetworkStackConguration
` CSMConguration
` OffboardSATAControllerConguration
` USBConguration
` IntelRMTConguration
gf: Select Screen
hi: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC: Exit
Boot Save & ExitSecurityAdvanced
