- 24 -
2-5 Save & Exit
& Save Changes and Reset
Press <Enter> on this item and select Yes. This saves the changes to the CMOS and exits the BIOS Setup
program. Select No or press <Esc> to return to the BIOS Setup Main Menu.
& Discard Changes and Reset
Press <Enter> on this item and select Yes. This exits the BIOS Setup without saving the changes made
in BIOS Setup to the CMOS. Select No or press <Esc> to return to the BIOS Setup Main Menu.
& Save Changes
Press <Enter> on this item and select Yes to save the changes to the CMOS. Select No or press <Esc>
to return to the BIOS Setup Main Menu.
& Discard Changes
Press <Enter> on this item and select Yes to cancel the BIOS changes. Select No or press <Esc> to return
to the BIOS Setup Main Menu.
& Restore Defaults
Press <Enter> on this item and select Yes to load the BIOS factory default settings. The BIOS defaults
settings help the system to operate in optimum state. Always load the Optimized defaults after updating
the BIOS or after clearing the CMOS values.
& Save as User Defaults
SavetocurrentBIOSsettingsasuser-deneddefaultsettings.
& Restore User Defaults
Loadtheuser-denedefaultsettingsforallBIOSoptions.
& Boot Override
Allows you to select a device to boot immediately. Press <Enter> on the device you select and select Yes
toconrm.Yoursystemwillrestartautomaticallyandbootfromthatdevice.
& LaunchEFIShellfromlesystemdevice
AllowsyoutolaunchtheEFIShellapplication(shell.e)fromoneoftheavailablelesystemdevices.Press
<Enter> on this option and the system will restart to the EFI Shell screen automatically.
Aptio Setup Utility - Copyright (C) 2015 American Megatrends, Inc.
Version 2.17.1249. Copyright (C) 2015 American Megatrends, Inc.
Main
Save Changes and Reset
Save Changes and Reset
Save Changes
Discard Changes
Default Options
Restore Defaults
Save as User Defaults
Restore User Defaults
Boot Override
LaunchEFIShellfromlesystemdevice
gf: Select Screen
hi: Select Item
Enter: Select
