Gigabyte ga-n3150n-d3v [3/28] Chapter 1 hardware installation
![Gigabyte ga-n3150n-d3v [3/28] Chapter 1 hardware installation](/views2/1167923/page3/bg3.png)
- 3 -
Table of Contents
GA-N3150N-D3V Motherboard Layout ............................................................................4
Chapter 1 Hardware Installation .....................................................................................5
1-1 Installation Precautions .................................................................................... 5
1-2 ProductSpecications ...................................................................................... 6
1-3 Installing the Memory ....................................................................................... 8
1-4 Installing an Expansion Card ........................................................................... 8
1-5 Back Panel Connectors .................................................................................... 8
1-6 Internal Connectors ........................................................................................ 10
Chapter 2 BIOS Setup ..................................................................................................15
2-1 Main ............................................................................................................... 16
2-2 Advanced ....................................................................................................... 17
2-3 Security .......................................................................................................... 21
2-4 Boot ................................................................................................................ 22
2-5 Save & Exit ..................................................................................................... 24
Chapter 3 Appendix ......................................................................................................25
Drivers Installation ..................................................................................................... 25
Regulatory Statements .............................................................................................. 26
Contact Us ................................................................................................................ 28
