Gigabyte ga-x150-plus ws [11/44] Center subwoofer speaker out orange

• Whenremovingthecableconnectedtoabackpanelconnector,rstremovethecablefrom

your device and then remove it from the motherboard.

• Whenremovingthecable,pullitstraightoutfromtheconnector.Donotrockitsidetosideto

prevent an electrical short inside the cable connector.

Center/Subwoofer Speaker Out (Orange)

Usethisaudiojacktoconnectcenter/subwooferspeakersina5.1/7.1-channelaudioconguration.

Rear Speaker Out (Black)

Thisjackcanbeusedtoconnectrearspeakersina4/5.1/7.1-channelaudioconguration.

Side Speaker Out (Gray)

Usethisaudiojacktoconnectsidespeakersina7.1-channelaudioconguration.

Line In (Blue)

The line in jack. Use this audio jack for line in devices such as an optical drive, walkman, etc.

Line Out (Green)

The line out jack. Use this audio jack for a headphone or 2-channel speaker. This jack can be used to

connectfrontspeakersina4/5.1/7.1-channelaudioconguration.

Mic In (Pink)

The Mic in jack.

PleasevisitGIGABYTE'swebsitefordetailsonconguringtheaudiosoftware.

- 11 -
