8) BAT (Battery)

 Thebatteryprovidespowertokeepthevalues(suchasBIOScongurations,date,andtimeinformation)

intheCMOSwhenthecomputeristurnedoff.Replacethebatterywhenthebatteryvoltagedropstoalow

level, or the CMOS values may not be accurate or may be lost.

You may clear the CMOS values by removing the battery:

1. Turn off your computer and unplug the power cord.

2. Gently remove the battery from the battery holder and wait for one minute. (Or

use a metal object like a screwdriver to touch the positive and negative terminals

ofthebatteryholder,makingthemshortfor5seconds.)

or uncertain about the battery model.

• Wheninstallingthebattery,notetheorientationofthepositiveside(+)andthenegativeside(-)

ofthebattery(thepositivesideshouldfaceup).

• Used batteries must be handled in accordance with local environmental regulations.

The PCI slots share bandwidth with the M2F_32G and SATA Express connectors. Whether the SATA

ExpressconnectorcanbeusedisdependentonthetypeofM.2SSDbeinginstalled.Pleasereferto

the table below:

SATA Express SATA3_0 SATA3_1 SATA3_2 SATA3_3 SATA3_4 SATA3_5

a a a a a a

a a a a a a

a: Available,r: Not Available

(Note1) The M.2 PCIex4SSDwillrunatx2speedifa PCI slot is populated.

(Note2) TheSATA3_5connectorwillbecomeunavailableifanM.2SATASSDisinstalled.

Connector
