- 4 -
Table of Contents
GA-H61M-S1 Motherboard Layout .................................................................................5
GA-H61M-S1 Motherboard Block Diagram ....................................................................6
Chapter 1 Hardware Installation .....................................................................................7
1-1 Installation Precautions ................................................................................... 7
1-2 ProductSpecications ..................................................................................... 8
1-3 Installing the CPU .......................................................................................... 10
1-4 Installing the Memory .....................................................................................11
1-5 Installing an Expansion Card ..........................................................................11
1-6 Back Panel Connectors ................................................................................. 12
1-7 Internal Connectors ....................................................................................... 13
Chapter 2 BIOS Setup .................................................................................................. 19
2-1 Startup Screen ............................................................................................... 20
2-2 The Main Menu .............................................................................................. 21
2-3 M.I.T. .............................................................................................................. 22
2-4 System ........................................................................................................... 30
2-5 BIOS Features ............................................................................................... 31
2-6 Peripherals ..................................................................................................... 34
2-7 Power Management ....................................................................................... 36
2-8 Save & Exit .................................................................................................... 37
Chapter 3 Drivers Installation .......................................................................................38
Regulatory Statements ............................................................................................. 39
