- 7 -
GA-H61N-USB3 Motherboard Layout
(Note 1) The LAN chip is located on the back of the motherboard.
(Note 2) The BIOS ash ROM is located below the latch on the PCIEX16 slot.
R_SPDIF
VGA_DVI
CPU_FAN
LGA1155
ATX
GA-H61N-USB3
F_AUDIO
M_BIOS
PCIEX16
DDR3_1
DDR3_2
BAT
ATX_12V
Intel
®
H61
USB_HDMI
USB_ESATA
CODEC
TPM
SATA2_1
Fresco
FL1009
iTE IT8728
CLR_CMOS
F_PANEL
F_USB2
F_USB1
SYS_FAN
SPDIF_O
PHASE LED
SATA2_0
B_BIOS
(Note 2)
Realtek
RTL8111E
(Note 1)
AUDIO
USB30_LAN
