12
Gigaset A420-A420A / Großbritannien / A31008-M2402-L101-1-7619 / Bali.fm / 19.04.2012
Template Bali, Version 1, 16.02.2012
Stopping and controlling playback
Controlling playback depends on the point in time at which the corresponding key is pressed.
During message playback:
Additional functions during message playback
Press the display key §Menu§. Playback stops.
Select the relevant function using
q:
Deleting an individual message
During playback: Press key
Q or the display key Ü .
New messages can on
ly be deleted during playback of message body.
Deleting all old messages
During playback or when paused:
§Menu§ ¤ q Delete all old ¤ §OK§ (Confirm the security prompt)
Accepting a call from the answering machine
You can accept a call while the answering machine is recording it:
§Menu§ ¤ Accept ¤ §OK§
You can also accept the call by:
◆ Pressing the talk key c
◆ Removing the handset from the base station/charger (if Auto Answer is activated ¢ page 24)
Recording stops and you can speak to the caller.
Operating when on the move (remote operation)
You can check your answering machine from any other telephone (hotel, pay phone etc.).
Prerequisites:
◆ You have set a system PIN other than 0000 (¢ page 24).
◆ The phone you are using for remote operation has tone dialling (DTMF) i. e., you hear different tones when you press
the keys.
Calling the answering machine and playing messages
~ (Dial your own number.) ¤ When you hear your announcement, press 9 and enter the system PIN.
The following keys are used for operation:
2
Pause playback. Press 2 again to resume.
t or 1
During playback of message header: Go to the start of the previous message. Skipping back from
the first message jumps to the last message.
During playback of message body: Go
to the start of the current message.
s or I
Go to the start of the next message. Skipping forward from the last message jumps to the first mes-
sage.
L
During playback of message header: Skip header.
During playback of message body: Go t
o the body of the next message. Skipping forward from the
last message jumps to the first message.
Dial Number Dial number.
Continue Continue message playback.
Volume Setting volume.
Copy to Dir. Copy the caller's number to the directory.
Delete all old Delete all old messages.
Please note
When C
all Screening is activa
ted on the handset and the call can already be heard on the handset, you can only
accept the call via
§Menu§ ¤ Accept ¤ §OK§. Pressing the talk key/handsfree key c only activates or deactivates the
handsfree mode.
A
During the number/date/time announcement: Skip to the start of the previous message.
During the message playback: Skip
to the start of the current message.
B
Stop playback. Press again to resume.
3
Go to the next message.
0
Delete current message.
