6
Gigaset A420-A420A / Großbritannien / A31008-M2402-L101-1-7619 / Bali.fm / 19.04.2012
Template Bali, Version 1, 16.02.2012
Display in idle status
Once the phone is registered and the time set, the idle status is shown as in this example.
Screen display
◆ Reception between the base station and the handset:
- Good to poor:
Ð ¨ § ¦
- No reception:
¥
◆ Activating the answering machine (A420A only):
- ± Your answering machine is activated.
◆ Battery charge status:
-
U Charged over 66%
-
V Charged between 34% and 66%
-
e Charged between 11% and 33%
-
= Charged less than 11%
-
= Flashes: batteries almost empty (less than 10 minutes talktime)
-
= e V U Batteries are charging
If No Radiation mode (
¢ page 24) is activated, the ½ icon is displayed in the top left.
Activating/deactivating the handset
Press and hold the a key to activate or deactivate the handset. If you place a deactivated handset in the base station
or charging cradle, it will automatically activate after approx. 30 seconds.
Your phone is now
re
ady for use.
If you have any questions about using your phone,
please read the tips on troubleshooting ("Questions and answers",
¢ page 19) or contact our Customer Care team ¢ page 20.
Menu guidance
Your telephone's functions are accessed via a menu consisting of several levels (menu overview ¢ page 23).
Main menu (first menu level)
¤
When the handset is in idle status, press the display key §Menu§ or right on the control key v to open the main menu.
The functions in the main menu are shown by means of an icon and the func
tion's name.
Selecting a function:
¤ You can scroll between functions using the control key q. The function is shown in the display.
¤ Press the display key §OK§ or the right control key vto select the displayed function. This opens the corresponding
submenu and the first entry is displayed.
If you press the display key
” or briefly the end call key a, the display returns to idle status.
Submenus
The functions in the submenu are indicated by name.
Selecting a function:
¤ You can scroll between functions using the control key q. The function is shown in the display.
¤ Press the display key §OK§ to select the displayed function. This opens the corresponding submenu and the first entry
is displayed.
If you press the display key
” or briefly the end call key a, the display returns to the previous menu level or you cancel
the operation.
Any settings you have not confirmed by pressing the display key
§OK§ are lost.
Reverting to idle status
From any point in the menu:
¤ Press and hold the end call key a or
¤ Do not press any key: after 2 minutes, the display will automatically revert to idle status.
Ð
Ã
U
INT 1
23.04. 10:53
‘
Menu
