ES1100 Series

8/16/24-port FE

Unmanaged Switch

ES1100 Series

8/16/24-port FE

Unmanaged Switch



Non-blocking, wire-speed

transmission



Auto MDI/MDI-X support



IEEE 802.3az compliant

(ES1100-16/24/24E)



Fanless design for silent

operations



IEEE 802.3x flow control

supported



IEEE 802.1p CoS supported



IEEE 802.3af power on up to

4/8 ports (ES1100-8P/16P)

The ZyXEL Switch ES1100 Series is designed for SMBs to boost business network

performance and efficiency. It enables businesses to enter the world of networking

connectivity without the need for complicated management. The Series provides not only

plug-and-play simplicity for high-bandwidth connectivity but also the N-way

Auto-negotiation functions to connect its network counterparts with the highest possible

data speed as well as to activate the duplex mode automatically. The ES1100 Series is Ideal

for typical noise-sensitive office environments for its superior energy efficiency and

Ethernet connectivity.

The ES1100 Series consists of four Fast Ethernet switches and two Power over Ethernet (PoE)

switches: the ZyXEL ES1100-16, ES1100-24, ES1100-24E and ES1100-24G; ES1100-8P and

ES1100-16P. The desktop design of ZyXEL ES1100-8P/16P/16/24E switch is ideal for SB or

SOHO users seeking reliable network connectivity that fits into rack environment easily,

while the ES1100-24/24G is designed for 19” racks, making it easy to be deployed in

standard wiring closets.

Benefits

Green networking

The environment-aware ES1100 Series offers 10/100M Ethernet speeds critical to the

next-generation network applications, and it also provides power-saving functions to reduce

energy consumption for lower operating cost.

Traffic detection — IEEE Energy Efficient Ethernet (EEE) compliance (ES1100-16/24/24E)

The feature automatically detects network traffics and adjusts power consumption accordingly in

a dynamic manner. It reduces power consumption during the low link utilization periods.

Inactive link detection

The power usage adjustment feature automatically reduces power usage when any shut down

network device or inactive link is detected. That is, power consumption of the Series can be

adjusted according to the link status or the number of active network devices when possible.

Cable length detection

The devices equipped with this green feature can automatically detect the length of connected

Ethernet cables and adjust power usage accordingly. The shorter the cable length, the less power it

consumes.

IEEE 802.3az-compliant Switch

with Decent Performance for

Small-group Networks
