Zyxel ES1100-16P [3/4] Specifications
![Zyxel ES1100-16P [3/4] Specifications](/views2/1168501/page3/bg3.png)
Standard Compliance
• IEEE 802.3 10Base-T Ethernet
• IEEE 802.3u 100Base-TX Fast Ethernet
• IEEE 802.ab 1000Base-T Ethernet
• IEEE 802.3af PoE
• IEEE 802.3x Flow control and Back-pressure
• IEEE 802.1p CoS
• IEEE 802.3az EEE
Certification
Safety
• EN 60950-1
• IEC 60950-1
• EU RoHS Compliant
Emission (EMC)
• FCC Part15 (Class A)
• CE EMC (Class A)
Specifications
Model ES1100-8P ES1100-16P ES1100-16 ES1100-24E ES1100-24 ES1100-24G
8-port FE 16-port FE 16-port FE 24-port FE 24-port FE 24-port FE
Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged Unmanaged
Product Name
PoE Switch PoE Switch Switch Switch Switch Switch
Port Density
10/100Base-T 4 8 16 24 24 24
10/100 Base-T PoE 4 8 - - - -
Dual personality GbE ports - - - - - 2
Performance
Switching Capacity (Gbps) 1.6 3.2 3.2 4.8 4.8 8.8
Switching Forwarding Rate (Mpps) 1.2 2.4 2.4 3.6 3.6 6.6
Packet Buffer 96 KB 160 KB 256 KB 256 KB 256 KB 320 KB
MAC Address 1K 8K 8K 8K 8K 8K
Jumbo frame support (up to 2048 bytes) - - Yes Yes Yes -
802.3x flow control prioritization Yes Yes Yes Yes Yes Yes
802.1p CoS Yes Yes Yes Yes Yes Yes
Broadcast Storm Control Yes Yes Yes Yes Yes Yes
Back-Pressure-Base flow control Yes Yes Yes Yes Yes Yes
Loop-detection - - Yes Yes Yes -
Auto MDI/MDI-X Yes Yes Yes Yes Yes Yes
Power Requirement
Input voltage of AC
PoE power budget 64 W 130 W - - - -
Physical Feature
Fanless Yes - Yes Yes Yes Yes
262 x 184 x 41/ 262 x 184 x 41/ 216 x 133 x 42/ 267 x 162 x 42/ 441 x 131 x 44/ 441 x 131 x 44/
Item dimensions (WxDxH)(mm/in.) 10.31 x 7.24 x 10.31 x 7.24 x 8.50 x 5.24 x 10.51 x 6.38 x 17.36 x 5.16 x 17.36 x 5.16 x
1.61 1.61 1.65 1.65 1.73 1.73
Item weight (kg/lb.) 1.4/3.09 1.7/3.75 0.77/1.70 1.28/2.82 1.35/2.98 1.5/3.31
318 x 275 x 73/ 318 x 275 x 73/ 325 x 227 x 71/ 325 x 227 x 71/ 477 x 222 x 71/ 477 x 222 x 71/
Packing dimensions (WxDxH)(mm/in.) 12.52 x 10.83 x 12.52 x 10.83 x 12.80 x 8.94 x 12.80 x 8.94 x 18.78 x 8.74 x 18.78 x 8.74 x
2.87 2.87 2.80 2.80 2.80 2.80
Packing weight (kg/lb.) 2.2/4.85 2.5/5.51 1.59/3.51 2.1/4.63 2.14/4.72 2.2/4.85
Environmental Specification
Operating temperature
Storage temperature
Operating humidity
0°C to 50°C/32°F to 122°F
100 - 240 V AC, 50/60 Hz
-40°C to 70°C/-40°F to 158°F
10% to 95% (non-condensing)
