Chapter 50 RIP Commands

Ethernet Switch CLI Reference Guide

166

• Sets the RIP direction in this routing domain to Both and the version to 2 with subnet

broadcasting (v2b); the Switch will send and receive RIP packets in this routing domain.

sysname(config)# router rip

sysname(config-rip)# exit

sysname(config)# interface route-domain 172.16.1.1/24

sysname(config-if)# ip rip direction Both version v2b
