Zyxel ES-3124-4F [78/250] Command examples

Chapter 17 GARP Commands

Ethernet Switch CLI Reference Guide

17.3 Command Examples

In this example, the administrator looks at the Switch’s GARP timer settings and decides to

change them. The administrator sets the Join Timer to 300 milliseconds, the Leave Timer to

800 milliseconds, and the Leave All Timer to 11000 milliseconds.

sysname# show garp

GARP Timer

------------------------

Join Timer :200

Leave Timer :600

Leave All Timer :10000

sysname# configure

sysname(config)# garp join 300 leave 800 leaveall 11000

sysname(config)# exit

sysname# show garp

GARP Timer

------------------------

Join Timer :300

Leave Timer :800

Leave All Timer :11000
