Ethernet Switch CLI Reference Guide
53
CHAPTER 11
Date and Time Commands
Use these commands to configure the date and time on the Switch.
11.1 Command Summary
The following table describes user-input values available in multiple commands for this
feature.
The following section lists the commands for this feature.
Table 32 time User-input Values
COMMAND DESCRIPTION
week Possible values (daylight-saving-time commands only): first, second,
third, fourth, last.
day Possible values (daylight-saving-time commands only): Sunday,
Monday, Tuesday, ....
month Possible values (daylight-saving-time commands only): January,
February, March, ....
o’clock Possible values (daylight-saving-time commands only): 0-23
Table 33 time Command Summary
COMMAND DESCRIPTION M P
show time Displays current system time and date. E 3
time <hour:min:sec> Sets the current time on the Switch.
hour: 0-23
min: 0-59
sec: 0-59
Note: If you configure Daylight Saving Time
after you configure the time, the Switch
will apply Daylight Saving Time.
C13
time date <month/day/year> Sets the current date on the Switch.
month: 1-12
day: 1-31
year: 1970-2037
C13
time timezone <-1200|...|1200> Selects the time difference between UTC (formerly
known as GMT) and your time zone.
C13
time daylight-saving-time Enables daylight saving time. The current time is
updated if daylight saving time has started.
C13
