![Zyxel ES-3124-4F [165/250] Rip commands](/views2/1168512/page165/bga5.png)
Ethernet Switch CLI Reference Guide
165
CHAPTER 50
RIP Commands
This chapter explains how to use commands to configure the Routing Information Protocol
(RIP) on the Switch.
50.1 RIP Overview
RIP is a protocol used for exchanging routing information between routers on a network.
Information is exchanged by routers periodically advertising a routing table. The Switch can
be configured to receive and incorporate routing table information sent from other routers, to
only send routing information to other routers, both send and receive routing information, or
to neither send nor receive routing information to or from other routers on the network.
50.2 Command Summary
The following section lists the commands for this feature.
50.3 Command Examples
This example:
• Enables RIP.
• Enters the IP routing domain 172.16.1.1 with subnet mask 255.255.255.0.
Table 107 rip Command Summary
COMMAND DESCRIPTION M P
show router rip Displays global RIP settings. E 3
router rip Enables and enters the RIP configuration
mode on the Switch.
C13
exit Leaves the RIP configuration mode. C 13
no router rip Disables RIP on the Switch. C 13
interface route-domain <ip-address>/<mask-
bits>
Enters the configuration mode for this
routing domain.
C13
ip rip direction
<Outgoing|Incoming|Both|None> version
<v1|v2b|v2m>
Sets the RIP direction and version in this
routing domain.
C13
