Chapter 23 Multicast
GS1920 Series User’s Guide
188
To set the Switch to forward the multicast group traffic to the subscribers, configure multicast group
settings in the Group Configuration screen. The following figure shows an example where two
IPv4 multicast groups (News and Movie) are configured for the multicast VLAN 200.
Figure 139 MVR Group Configuration Example
Figure 140 MVR Group Configuration Example
EXAMPLE
EXAMPLE
