HP 250, f0y88ea [15/162] Amd models 7
![HP 250, f0y88ea [15/162] Amd models 7](/views2/1169087/page15/bgf.png)
Category Description Non-touch; UMA Touch; UMA
OTP support
Operating
system
Preinstalled:
●
Windows 8.1
√√
●
Ubuntu √
●
FreeDOS √
Serviceability End-user replaceable parts:
●
AC adapter
●
Battery
●
Memory modules (2)
●
Optical drive
●
WLAN module
√√
AMD models
Category Description Non-touch;
UMA
Non-touch;
discrete
Touch;
UMA
Touch;
discrete
Product name HP 15 Notebook PC √√√√
HP 15 TouchSmart Notebook PC √√√√
Compaq 15 Notebook PC √√√√
Compaq 15 TouchSmart Notebook PC √√√√
HP 255 G2 Notebook PC √√√√
Processors AMD A6-5200 (2.0 GHz, 2 MB cache, 25W √ √
AMD A4-5000 (1.5 GHz, 2 MB cache, 15W) √√√√
AMD E2-3800 (1.3 GHz, 1 MB cache, 15W) √ √
AMD E1-2100 (1.0 GHz, 1 MB cache, 9W) √√√√
HP Quad-Core, (1.55 GHz, 13W) √√√√
Intel Quad-Core, (1.55 GHz, 13W) √√√√
Intel Celeron HP Dual-Core, (1.05 GHz, 8W √√√√
Dual-Core, (1.05 GHz, 8W) √√√√
Chipset Integrated SOC FCH √√√√
Graphics Switchable discrete graphics:
AMD Sun LE (18W) Radeon™ HD 8570M with up to 1024 MB of
dedicated video memory (128Mx16 DDR3 1GHz x 4 PCs)
Support HD Decode, DX11, and HDMI
Support HD Decode, DX11.1, and HDMI
Support PX 7.0
√ √
AMD models 7
