1 Product description
Intel HM76 Express Chipset models
Category Description Non-touch ;
UMA
Non-touch;
discrete
Touch;
UMA
Touch;
discrete
Product name HP 15 Notebook PC √√√√
HP 15 TouchSmart Notebook PC √√√√
Compaq 15 Notebook PC √√√√
Compaq 15 TouchSmart Notebook PC √√√√
HP 250 G2 Notebook PC √√√√
Processors Intel i5-3230M processor (2.6-GHz, 3-MB cache, 35 W) √√√√
Intel i3-3110M processor (2.4-GHz, 3-MB cache, 35 W) √√√√
Intel Pentium 2020M processor (2.4-GHz, 2-MB cache, 35 W) √√√√
Intel Celeron 1000M processor (1.8-GHz, 2-MB cache, 35 W) √√√√
Chipset Intel HM76 Express √√√√
Graphics Switchable discrete graphics:
Nvidia 820M N15V-GM 1 GB VRAM (128Mx16 DDR3 1GHz x 4
PCs)
GPU power management enabled at launch
Support DX11
Support dynamic switching
Support HD Decode and HDMI
√ √
UMA graphics:
Intel HD Graphics √ √
Panel 39.6-cm (15.6-in), high-definition (HD), light-emitting diode
(LED), SVA BrightView (1366×768) display; typical brightness:
200 nits
√√√√
Touchscreen, 39.6-cm (15.6-in), high-definition (HD), light-
emitting diode (LED), SVA AntiGlare (1366×768) display; typical
brightness: 200 nits
Supports 16:9 ultra wide aspect ratio
√√
Supports LVDS √√√√
Memory 2 customer-accessible/upgradable memory module slots
Supports dual-channel memory
DDR3L-1600-MHz
√√√√
Intel HM76 Express Chipset models 1
