Zyxel UAG4100 [162/323] Command description
![Zyxel UAG4100 [162/323] Command description](/views2/1169094/page162/bga2.png)
Chapter 29 Payment Service
UAG CLI Reference Guide
162
[no] payment-service page-
customization
Sets the UAG to use a custom online payment service page.
You can customize the online payment service pages that displays after an
unauthorized user click the link in the Web Configurator login screen to
purchase access time
The no command sets the UAG to use the default online payment service
page built into the device.
payment-service profile-page
selection-message message
Configures a note to display in the first welcome page that allows users to
choose a billing period they want.
payment-service provider paypal Enters the payment-service-paypal sub-command mode to configure the
PayPal account information. See Table 95 on page 163 for the sub-
commands.
payment-service provider select paypal Selects to use PayPal to authorize credit card payments.
payment-service sms-page info-message
message
Specifies a note to display if you set the UAG to send account information
via SMS text messages.
payment-service success-page account-
message message
Configures a note to display above the user account information.
payment-service success-page format-
date {dd-mm-yyyy | mm-dd-yyyy | yyyy-
mm-dd} format-time {12-hour | 24-hour}
Sets the format in which you want to display the date and how long an
account is allowed to stay un-used before it expires.
payment-service success-page
notification-message message
Specifies the important information you want to display.
payment-service success-page
notification-message-color {#00FF00 |
color_name | rgb(0,0,255)}
Specifies the font color of the important information. You can use the color
name, hexadecimal codes, or enter decimal color code of your own.
payment-service success-page
successful-message message
Specifies a note to display in the second page after the user’s online
payment is made successfully.
show payment-service account-delivery Displays whether the UAG is to display the user account information in the
web screen and/or send account information in a text message to the user’s
mobile device.
show payment-service activation Displays whether the online payment service is enabled.
show payment-service fail-page
settings
Shows the message that displays when the user’s online payment failed.
show payment-service page-
customization
Displays whether the UAG is to use a custom online payment service page
or the default online payment service page built into the device.
show payment-service profile-page
settings
Shows the message that displays in the first welcome page to have users
choose a billing period they want.
show payment-service provider paypal Displays your PayPal account information.
show payment-service provider select Displays the name of online payment service provider used by the UAG to
authorize credit card payments.
show payment-service sms-page settings Shows the note that displays in the text message when you set the UAG to
send account information via SMS text messages.
show payment-service success-page
settings
Shows all the information or messages that display in the page after the
user’s online payment is made successfully.
Table 94 payment-service Commands (continued)
COMMAND DESCRIPTION
