Chapter 37 User/Group
UAG CLI Reference Guide
202
37.2.1.1 Username Setting Command Examples
The following commands create a new user account and show the user information.
37.2.2 User Group Commands
This table lists the commands for groups.
username username [no] logon-re-auth-time
<0..1440>
Sets the reauthentication time for the specified user. Set it to
zero to set unlimited reauthentication time. The
no command
sets the reauthentication time to thirty minutes (regardless of
the current default setting for new users).
username username logon-re-auth-type {due-time |
re-auth-time}
Sets whether the specified user will be logged out and have to
log into the UAG again according to the due time or
reauthentication time settings.
username rename username username Renames the specified user (first username) to the specified
username (second username).
Table 118 username/groupname Commands Summary: Users (continued)
COMMAND DESCRIPTION
Router# configure terminal
Router(config)# username test password 1234 user-type guest
Router(config)# username test logon-due-time 07:30
Router(config)# username test logon-re-auth-type due-time
Router(config)# show username test
username : test
password : $1$gRsjDU29$rh1PqNQyspuqhoqgC3nlM1
description : Local User
user type : guest
time setting : manual
lease time : 1440
re-auth type : due-time
re-auth time : 1440
due time : 07:30
reference count : 0
Router(config)#
Table 119 username/groupname Commands Summary: Groups
COMMAND DESCRIPTION
show groupname [groupname] Displays information about the specified user group or about all user groups
set up in the UAG.
[no] groupname groupname Creates the specified user group if necessary and enters sub-command
mode. The
no command deletes the specified user group.
[no] description description Sets the description for the specified user group. The no command clears
the description for the specified user group.
[no] groupname groupname Adds the specified user group (second groupname) to the specified user
group (first groupname).
[no] user username Adds the specified user to the specified user group.
show Displays information about the specified user group.
groupname rename groupname groupname Renames the specified user group (first groupname) to the specified group-
name (second groupname).
