Chapter 16 LEDs
NWA5000 / WAC6000 Series User’s Guide
181
Figure 105 Maintenance > LEDs > Suppression
The following table describes fields in the above screen.
16.3 Locator Screen
The Locator feature identifies the location of your WAC among several devices in the network. You
can run this feature and set a timer in this screen.
To run the locator feature, enter a number of minutes and click Turn On button to have the WAC
find its location. The Locator LED will start to blink for the number of minutes set in the Locator
screen. The default setting is 10 minutes. While the locator is running, the turn on button will grey
out and return after it’s finished. If you make changes to the time default setting, it will be stored
as the defualt when the WAC restarts.
Note: The Locator feature is not affected by the Suppression setting.
To access this screen, click Maintenance > LEDs > Locator.
Table 83 Maintenance > LED > Suppression
LABEL DESCRIPTION
Suppression On If the Suppression On check box is checked, the LEDs of your NWA/WAC will turn
off after it’s ready.
If the check box is unchecked, the LEDs will stay lit after the NWA/WAC is ready.
Apply Click Apply to save your changes back to the NWA/WAC.
Reset Click Reset to return the screen to its last-saved settings.
