(93IO) "ISO" BOAT W/O MOTOR MOUNTING (TYPE I) ENGLISH 7.5” X 10.3” 04/29/2013

SAVE THESE INSTRUCTIONS

Page 7

1. Insert “Shaft A” with the pin end first into the blade. Make sure the pin is securely fastened to the

blade.

2. Insert the assembled “Shaft A” through the oar-lock with the blade towards outboard (water).

3. Place the retainer ring onto the other end of the assembled “Shaft A”, from inside of the boat.

4. Join “Shaft A” with “Shaft B” together by inserting them together into the coupler and tighten the

coupler covers securely.

5. When the oars are not in use secure the oars onto the oar holders located on each side of the

boat.

Oar Assembly (Certain Models):

Coupler Cover

Shaft B

Coupler

Shaft A

Blade

Retainer Ring

FRENCH OARS:
