Chapter 7-1
Setting Robomow and using Advanced Features
Chapter 7 Setting Robomow and using
Advanced Features
7.1 Manual User Options
P Remove the Manual Controller
from its holder.
The display changes to Manual User
Options
P Press
once to select
Manual user options and get to
the next screen: “Settings”.
P Use the
arrows to scroll
through the other “Manual User
options” menu.
P General navigation rules
) Use the
button
to select a menu item or
confirm a selection.
) Use the
button at any time to return to the main menu
) Use the Up/Down
arrows to toggle between enable/
disable options when appropriate.
When you get to the option to be selected, press
to
select it or to confirm.
7.2 Settings
Robomow offers several setting options. The Settings menu is the doorway to
all those possibilities.
P Get to the Settings menu.
P Press
to select “Settings” and start the list of Robomow’s
setting options.
“Zones setup” option is the first option to be displayed.
P Use the arrow keys to go through the list, until you get to the option
you wish to set.
) Press
at the display of that option, to select it and to
start the process of setting it.
