Introduction - 7
Introduction
What’s in the Boxes
1 Robomow
®
9
Base Station wheel supports Used for sup-
porting Robomow drive wheels when entering
and departing the Base Station.
17
Wire connectors
Used for splicing wires (as needed).
2 Power Pack 10
Screws x2
Used for assembling the Base Station wheel
supports to the Base Station.
18
Plot connector
Used for connecting the completed
perimeter wire set-up to the perimeter
switch/Base Station.
3
Perimeter Wire
Used to create a virtual wall for your Robomow.
11
Extension cord (15meters low voltage
cable)
19
Screws x2
Used for assembling the Base Station
Cover to the Base.
4 Pegs - Used for securing the wire to the ground. 12 Outdoor power supply 20 Perimeter Switch
5 Assembled Base Station. 13
Base Station Stakes - Used for securing the Base
Station to the ground.
21
Perimeter Switch Stake - Used to
hold the perimeter switch vertical to the
ground.
6
Base Station Cover
Used for recharging the Robomow Power Pack
and activates the perimeter wire.
14 Operating & Safety Manual 22
Power Supply for Perimeter Switch
– Used for operating the perimeter
switch. Batteries available as an ac-
cessory
7
Base - Used for directing the Robomow to the
charging contacts.
15 DVD – Setup and Operation video. 23
Power Supply
(for charging Robomow)
8
Charging Fence
Used for preventing the Robomow to climb on
the Base Station during operation.
16
RoboRuler
Used for setting the distance of the perimeter
wire from the lawn edge.
Introduction
Introduction 7
What’s in the Boxes
1
Robomow
®
9
Base Station wheel supports Used
for supporting Robomow drive
wheels when entering and departing
the Base Station.
17
Wire connectors
Used for splicing wires (as
needed).
2 Power Pack 10
Screws x2
Used for assembling the Base
Station wheel supports to the Base
Station.
18
Plot connector
Used for connecting the completed
perimeter wire set-up to the
perimeter switch/Base Station.
3
Perimeter Wire
Used to create a virtual wall for your
Robomow.
11
Extension cord (15meters low
voltage cable)
19
Screws x2
Used for assembling the Base
Station Cover to the Base.
4
Pegs - Used for securing the wire to the
ground.
12 Indoor Power Supply 20
Power Supply holder (+ screws
and dowels) Used for fixing the
Power Supply to a wall.
5 Assembled Base Station. 13
Base Station Stakes - Used for securing
the Base Station to the ground.
21
Perimeter Switch
6
Base Station Cover
Used for recharging the Robomow Power
Pack and activates the perimeter wire.
14 Operating & Safety Manual 22
Perimeter Switch Stake - Used to
hold the perimeter switch vertical to
the ground.
7
Base - Used for directing the Robomow
to the charging contacts.
15 DVD – Setup and Operation video. 23
Power Supply for Perimeter
Switch – Used for operating the
perimeter switch. Batteries
available as an accessory
8
Charging Fence
Used for preventing the Robomow to
climb on the Base Station during
operation.
16
RoboRuler
Used for setting the distance of the
perimeter wire from the lawn edge.
24
Power Supply
(for charging Robomow)
2
1
3
4
5
6
7
8
9
11
12
13
15
10
19
17
18
20
RL2000 ONLY
14
21
22
23
24
16
RL555/855ONLY
Operating & Safety Manual
RL MODELS
WWW.ROBOMOW.COM / WWW.ROBOMOW.EU
DOC0100D
20
21
22
23
RL2000 ONLY
RL555/855 ONLY
