Robomow RS630 [7/56] What s in the box
![Robomow RS630 [7/56] What s in the box](/views2/1172815/page7/bg7.png)
VII
Introduction
EN
1 Robomow
®
6 Operating & Safety Manual 11
Extension Cable
20 meters (65 ft.), (Low voltage cable).
2
Perimeter Wire
Used to create a virtual wall for your Robomow.
7
Remote Control (supplied with RS630
only, not available in all markets)
Used to manually drive and mow anywhere.
12
Power Box
Used to deactivate (halt) the automatic
operation mode and reactivate it as
needed. Also provides indication of
Robomow’s status (Docking or Operating)
and the Perimeter Wire’s health.
3
Pegs
Used for securing the wire to the ground.
8
RoboRuler
Used for setting the distance of the Perimeter
Wire from the lawn edge.
13
Power Box Mount
Used for fixing the Power Box to a wall.
(including Screws and dowels).
4
Wire Connectors
Used for splicing wires (as needed).
9
Assembled Base Station
Used by Robomow to dock and charge when
it is not mowing.
14
Template
Used for installing a Narrow Pass.
5
Plot Connector
Used for connecting the Perimeter Wire to the
Base Station.
10
Base Station Stakes
Used for securing the Base Station to the ground.
What’s in the Box
21 3 7 6
11
12
13
14
109
4
5
8
Wall Edge 40cm (15.5”)
Lawn Edge 35cm (14”)
Narrow Pass 14cm (5.5”)
for RS models
15
7
