Robomow S models

Main Parts

Robomow

1. Operating Lamp

2. Bumper with touch sensitive sensors

3. STOP Button / Carrying Handle

4. Operating Panel

Under the Hood

1. Bumper Door

2. Mowing Height Indicator

3. Mowing Adjustment Knob

4. Safety Switch

Base Station

1. Base Station Head (Charging Adaptor)

2. Base

3. Flippers (x2)

4. Stakes (x6)

Power Box

1. Docking Indicator

2. Program ON/OFF button

3. Operating Indicator

4. Wire Indicator

4 3 2 1
