DSL-584T ADSL Router User Guide

Access the Configuration Manager

In order to make sure your computer’s IP settings allow it to communicate with the Router, it is advisable to configure

your system be a DHCP client – that is, it will get IP settings from the Router. Appendix B describes how to configure

different Windows operating systems to “Obtain IP settings automatically”.

Note

Be sure that the web browser on your computer is not configured to use a proxy server in the

Internet settings. In Windows Internet Explorer, you can check if a proxy server is enabled using the

following procedure:

1. In Windows, click on the Start button and choose Control Panel.

2. In the Control Panel window, click on the Network and Internet Options icon.

3. In the Network and Internet Connections window, click the Internet Options icon.

4. In the Internet Properties window, click on the Connections tab and click on the LAN Settings

button

5. Verify that the “Use a proxy server for your LAN (These settings will not apply to dial-up or VPN

connections).” option is NOT checked. If it is checked, click in the checked box to deselect the

option and click OK.

Alternatively, you can access this Internet Options menu using the Tools pull-down menu in

Internet Explorer.

To use the web-based management software, launch a suitable web browser and direct it to the IP address of the Router.

Type in http:// followed by the default IP address, 192.168.1.1 in the address bar of the browser. The URL in the

address bar should read: http://192.168.1.1.

A dialog box prompts for the User Name and Password. Type in the default User Name “admin,” and the default

Password “admin” then click the OK button to access the web-based manager.

Enter Password

You should change the web-based manager access user name and password once you have verified that a connection

can be established. The user name and password allows any PC within the same subnet as the Router to access the web-

based manger.

Note

The user name and password used to access the web-based manager is NOT the same as the

ADSL account user name and password needed for PPPoE/PPPoA connections to access the

Internet.
