DSL-584T ADSL Router User Guide

LAN Clients

The LAN Clients window is used when establishing port forwarding rules in the Virtual Server and Filters windows.

This window can be accessed directly by clicking on the LAN Clients button in the Advanced tab. In order to use these

advanced features it is necessary to have IP addresses available for configuration. If there are no IP addresses listed in

the LAN Clients window, you will not be able to access the Virtual Server window.

Use the LAN Clients window to add or delete static IP addresses for the advanced functions mentioned above, or to

Reserve a Dynamically assigned IP address for an advanced function. Dynamically assigned IP addresses will only be

listed if DHCP is enabled on the Router.

LAN Clients window

To add a static IP address to the list of available IP addresses, type an IP address that falls within the range a available

IP addresses and click on the Add button. In the example above, available addresses range from 1.0.0.1 to

223.255.255.254. Any addresses added will appear in the list of Static Addresses available for advanced configuration.

To delete an IP address from the list of Static Addresses, click the Delete box for the address or addresses you want to

eliminate and click on the Apply button.

Dynamically assigned IP addresses may be reserved so that the lease does not expire for the LAN IP address. Click the

Reserve box for the address or addresses you want to reserve and click the Apply button. These addresses will become

Static IP addresses and will no longer be available for DHCP assignment.
