DSL-584T ADSL Router User Guide

2. Under the ATM VC Settings at the top of the window should not be changed unless you have been instructed to

change them. However, if you are instructed to change the VPI or VCI values, type in the values assigned for

your account. Leave the PVC and Virtual Circuit setting at the default (Pcv0 and Enabled) values for now. This

can be used later if you are configuring multiple virtual circuits for your ADSL service. For more information on

ATM VC Settings, see the table on page

32 below.

3. Under the Dynamic IP heading, choose the Connection Type from the pull-down menu. This defines both the

connection type and encapsulation method used for your ADSL service. The available options are 1483 Bridged

IP LLC and 1483 Bridged IP VC-Mux. If have not been provided specific information for the Connection Type

setting, leave the default setting.

4. Some ISPs record the unique MAC address of your computer’s Ethernet adapter when you first access their

network. This can prevent the Router (which has a different MAC address) from being allowed access to the

ISPs network (and the Internet). To clone the MAC address of your computer’s Ethernet adapter, type in the

MAC address in the Cloned MAC Address field and click the Clone MAC Address button.

5. Leave the MTU value at the default setting (default = 1400) unless you have specific reasons to change this (see

table below).

6. NAT should remain Enabled. If you disable NAT, you will not be able to use more than one computer for

Internet connections. NAT is enabled and disabled system-wide, therefore if you are using multiple virtual

connections, NAT will disabled on all connections.

7. The Firewall should remain enabled for most users. If you choose to disable this you will not be able to use the

features configured in the Firewall Configuration and Filters windows located in the Advanced directory. See

the next chapter for more details on these windows.

8. Most users will not need to change ATM settings. If this is the first time you are setting up the ADSL connection

it is recommended that you leave the Service Category settings at the default values until you have established

the connection. See the table on page

29 for a description of the parameters available for ATM traffic shaping.

9. When you are satisfied that all the WAN settings are configured correctly, click on the Apply button.

10. The new settings must be saved and the Router must be restarted for the settings to go into effect. To save and

reboot the Router, click on the Tools directory tab and then click the System button. In the System Settings

window, click the Save and Reboot button under Save Settings and Reboot the System.

11. Click OK when the following “Save and restart?” dialog box opens.

12. The Router will save the new settings and restart. Upon restarting the Router will automatically establish the

WAN connection.

Additional settings for Dynamic IP Address connections:

Dynamic IP Parameters Description

Connection Type

This specifies the connection type and encapsulation method used for your

Dynamic IP Address connection. The options available are

Bridged IP LLC

Bridged IP VC-Mux

Cloned MAC Address

This is not always necessary, but may be required for some ISPs. Type in

the MAC address of your computer’s Ethernet adapter in the Cloned MAC

Address field and click the Clone MAC Address button. This will copy the

information to a file used by the Router to present to the ISP’s server used
