DSL-584T ADSL Router User Guide

To set up a PPPoE or PPPoA connection:

1. If not already selected, choose the PPPoE/PPPoA option from the WAN Settings pull-down menu.

PPPoE/PPPoA is selected by default if you are configuring the Router for the first time.

2. Under the ATM VC Settings at the top of the window should not be changed unless you have been instructed to

account. Leave the PVC and Virtual Circuit setting at the default (Pcv0 and Enabled) values for now. This can be

used later if you are configuring multiple virtual circuits for your ADSL service. For more information on ATM

This defines both the connection protocol and encapsulation method used for your ADSL service. The available

options are PPPoA VC-Mux, PPPoA LLC and PPPoE LLC. If have not been provided specific information for the

Connection Type setting, leave the default setting.

5. Leave the MTU value at the default setting (default = 1400) unless you have specific reasons to change this (see

7. Leave the Default Route enabled if you want to use the Router as the default route to the Internet for your LAN.

Whenever a computer on the LAN attempts to access the Internet, the Router becomes the Internet gateway to the

the next chapter for more details on these windows.

10. Typically the globally IP settings (i.e. IP address for the WAN interface) for a PPPoA or PPPoA connection will

use Dynamic IP assignment from the ISP. Some accounts may be assigned a specific global IP address. If you

12. Most users will not need to change ATM settings. If this is the first time you are setting up the ADSL connection

it is recommended that you leave the Service Category settings at the default values until you have established the

15. Click OK when the following “Save and restart?” dialog box opens.

20
