21
Specications
Specification Comparison Table
Z170A GAMING
M3
H170 GAMING
M3
B150 GAMING
M3
Chipest Z170 H170 B150
Supports DDR4
Frequency (MHz)
3600(OC),
3200(OC),
3000(OC),
2800(OC),
2600(OC),
2400(OC), 2133
2133 2133
Supports M.2 Interface PCIe, SATA PCIe, SATA SATA
Supports U.2 Card Yes Yes No
SATAe ports 2 1 1
Supports RAID 0,1,5,10 Yes Yes No
M.2, SATA and SATAe
ports maximum support
1x M.2 SSD +
2xSATAe HDDs
+ 2xSATA HDDs
1x M.2 SSD +
1xSATAe HDD +
4xSATA HDDs
1x M.2 SSD +
1xSATAe HDD +
4xSATA HDDs
Supports Intel
®
Smart
Response Technology
Yes Yes No
USB 3.1 Gen2 ports on
the back panel
2 0 0
USB 2.0 ports on the
rear back panel
4 6 6
Supports Intel
®
Small
Business Advantage
No Yes Yes
