Proper use of the CatEye V3
Observe the following instructions for safe usage.
The meaning of icons in this manual:
Warning!!! : Sections marked with these icons are critical for safe use of the device.
Be sure to follow these instructions.
Caution : Important cautionary notes on the use and operation of the V3.
* Helpful tips are highlighted with asteriks.
Warning!!! :
• Pace maker users should never use this device.
• Do not concentrate on the data while riding. Always be sure to ride safely.
• Do not leave any battery within the reach of children, and dispose of them correctly.
If a battery is swallowed, consult a doctor immediately.
Caution:
• Regularly check the positions of the magnets and the speed/cadence sensors and make
sure that they are securely mounted. Tighten it firmly if there is any looseness.
• Avoid leaving the main unit / wireless sensor in direct sunlight for extended periods of time.
• Do not disassemble the computer, heart rate sensor, or speed sensor.
• Do not subject the computer, heart rate sensor, or speed sensor to strong impact; take
care also to prevent any of them from falling.
• Do not use paint thinner or rubbing alcohol to clean the unit.
• Stop using the unit if you have skin irritation with the HR strap or electrode pad.
• Do not twist or pull strongly the heart rate sensor.
• The heart rate sensor may deteriorate due to long-term use.
Replace the heart rate sensor if it has frequent measurement errors.
• As a nature of liquid crystal displays, sunglasses with polarized lens may block the visibility.
2.4GHz digital wireless system
2.4GHz-frequency digital wireless technology, which is the same technology used for
wireless LAN, is used for both the speed/cadence integrated speed sensor and the heart
rate sensor. This technology practically eliminates interference from external noise and
cross-talk with other wireless computer users, and enables to store highly reliable data.
However, in a very rare occasions, objects and places may generate strong electromag-
netic waves and interference, which may result in incorrect measurement:
• TV, PC, radios, motors/engines, or in cars and trains.
• Railroad crossings and near railway tracks, around television transmitting stations and
radar bases.
• Other wireless computers or digitally controlled lights.
Contents
Introduction .......................................... 1
About the manuals ............................... 1
Proper use of the CatEye V3 ................. 3
Description of computer and its parts .... 4
Computer ......................................... 4
Accessories ...................................... 4
Screen display ...................................... 5
How to install the unit on your bicycle ... 6
1. Attach the bracket to the stem or
handlebar ..................................... 6
2. Mount the speed sensor and
magnet ......................................... 7
3. Remove/Install the computer ....... 8
Heart rate sensor .................................. 9
Before wearing the heart rate sensor .... 9
Wearing the heart rate sensor .......... 9
Preparing the computer ...................... 10
Removing the insulation sheet ....... 10
1. Formatting/Restarting operation .... 11
2. Date/Clock setting ...................... 11
3. Tire circumference input ............. 12
4. Set the sensor ID ........................ 13
5. Selecting speed unit ................... 14
6. Operation test ............................. 15
Sensor signal status ....................... 15
Basic operation of the computer ........ 16
Functions on the measurement
screen ............................................ 16
Starting/Stopping the
measurement ................................. 17
Backlight ........................................ 17
Resetting the measurement data .... 17
Power-saving function .................... 17
Measurement screen .......................... 18
Upper and middle display data ....... 18
Lower display data ......................... 19
Pace function ................................. 20
Lap function ................................... 20
Countdown distance ....................... 21
Target heart rate zone ..................... 22
Changing the computer configuration ... 23
File view (FILE VIEW) ..................... 24
Setting the clock/date
(CLOCK.DATE) ................................ 28
Wheel selection and tire
circumference (WHEEL) ................. 29
Searching the sensor ID
(SEnSOR-ID) ................................... 29
Setting the measurement unit
(UnIT) ............................................. 31
Total distance manual entry
(ODO InPUT) .................................. 31
Setting the auto-mode
(AUTO MODE) ................................. 32
Setting the countdown distance
(C.D.DST
→→
→→
→) .................................. 32
Setting sound (SOUnD) .................. 33
Setting the target heart rate zone
(HR.ZOnE) ...................................... 34
Heart rate training .............................. 35
1. Improving general fitness ........... 35
2. Training for competition ............. 36
3. Use of the target zone ................ 37
Trouble shooting ................................ 38
Trouble on display .......................... 38
Trouble on operation ...................... 40
Replacing battery ............................... 41
Computer ....................................... 41
Heart rate sensor ............................ 41
Speed sensor ................................. 41
Maintenance ....................................... 42
Spare accessories .............................. 42
Specifications ..................................... 43
Registration ........................................ 44
Limited warranty ................................ 44
