Nikon 1 s2 kit 11-27.5mm white [162/236] Flash compensation

142

Flash compensation alters flash output

from the level suggested by the camera,

changing the brightness of the main sub-

ject relative to the background. Choose

from values between –3 EV (darker) and

+1 EV (brighter) in increments of

3 EV; in

general, positive values make the subject brighter while nega-

tive values make it darker.

A Y icon is displayed when flash com-

pensation is in effect. Normal flash out-

put can be restored by setting flash

compensation to ±0. Flash compensa-

tion is not reset when the camera is

turned off.

Choose Enable when using an optional underwater flash unit.

Flash Compensation

Underwater Flash
