8
- for normal drilling as well as for screwdriving set switch
C in position “1” and switch E in position “0” and use
adapter J 2
- the hammer mechanism is activated by applying a
slight pressure on the tool when the drill bit is in
contact with the workpiece
- best hammer drilling results can be obtained by only a
slight pressure on the tool needed to keep the
automatic clutch engaged; drilling performance will not
improve by applying more pressure on the tool
• Chiseling 9
! select operating mode only when tool is switched
off and plug is disconnected
- rst set switch E as well as switch C in position “1”
- rotate chisel into desired position
- then maintain switch E in position “1”, but set switch C
in position “0”
• Mounting adapter J 0
! clean and lightly lubricate the SDS+ adapter
before insertion
- pull back locking sleeve F 2 and insert adapter in
SDS+ chuck while turning and pushing it until it
engages; the adapter locks in position automatically
- pull adapter to check whether is it locked correctly
• Changing bits !
! clean and lightly lubricate the SDS+ accessory
before insertion
- pull back locking sleeve F 2 and insert accessory in
SDS+ chuck while turning and pushing it until it
engages; the accessory locks in position automatically
- pull accessory to check that it is locked correctly
- remove accessory by pulling back locking sleeve F
! the SDS+ accessory requires freedom of
movement which causes eccentricity when tool is
off-load; however, the accessory automatically
centres itself during operation without affecting
drilling precision
! only use sharp bits/chisels
! do not use bits/chisels with a damaged shank
• Safety clutch
If the accessory gets jammed, the drive to the spindle is
interrupted (causing a rattling noise)
- immediately switch o tool
- remove the jammed accessory
- switch on tool again
• Adjusting drilling depth @
• AUTO-STOP Carbon brushes
- this tool is equipped with carbon brushes which pop
up automatically when worn, thus preventing the motor
from being damaged
- when the tool stops unexpectedly, send it to your
dealer or the nearest SKIL service-station for having
the brushes replaced
• Holding and guiding the tool #
! while working, always hold the tool at the
grey-coloured grip area(s)
- always use auxiliary handle G 2 (can be adjusted
as illustrated)
- keep the ventilation slots uncovered
- do not apply too much pressure on the tool; let the tool
do the work for you
APPLICATION ADVICE
• When drilling ferrous metals
- pre-drill a smaller hole, when a large hole is required
- lubricate drill bit occasionally with oil
• When turning in a screw at/near the cross cut end or an
edge of wood, pre-drill a hole in order to avoid cracking of
the wood
MAINTENANCE / SERVICE
• After approximately 30 working hours rell grease
storage H with 30 grams of grease $
• Always keep tool and cord clean (especially the
ventilation slots)
! disconnect the plug before cleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skilmasters.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2012/19/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol % will remind you of this when the need for
disposing occurs
DECLARATION OF CONFORMITY
• We declare under our sole responsibility that the product
described under “Technical data” is in conformity with the
following standards or standardization documents: EN
60745, EN 61000, EN 55014, in accordance with the
provisions of the directives 2004/108/EC, 2006/42/EC,
2011/65/EU
• Technical file at: SKIL Europe BV (PT-SEU/ENG1),
4825 BD Breda, NL
