![Qnap ts-431 Инструкция по эксплуатации онлайн [84/344] 162186](/views2/1178032/page84/bg54.png)
84
initiator has connected to it yet.
Connected
The iSCSI target has been
connected by an initiator.
Disconnected
The iSCSI target has been
disconnected.
Offline
The iSCSI target has been
deactivated and cannot be
connected by the initiator.
LUN
Enabled
The LUN is active for connection
and is visible to authenticated
initiators.
Disabled
The LUN is inactive and is invisible
to the initiators.
Refer to the table below for actions (the "Action" button) available to manage iSCSI
targets and LUNs:
Action
Description
Deactivate
Deactivate a ready or connected target. Note that the
connection from the initiators will be removed.
Activate
Activate an offline target.
Modify
Modify the target settings: target alias, CHAP information, and
checksum settings.
Modify the LUN settings: LUN allocation, name, disk volume
directory, etc.
Delete
Delete an iSCSI target. All the connections will be removed.
Disable
Disable an LUN. All the connections will be removed.
Enable
Enable an LUN.
Un-map
Un-map the LUN from the target. Note that a LUN must first be
disabled before it can be un-mapped. When clicking this button,
the LUN will be moved to the un-mapped iSCSI LUN list.
Map
Map the LUN to an iSCSI target. This option is only available on
