TD-W8151N

150Mbps Wireless N ADSL2+ Modem Router User Guide

Chapter 2 Hardware Installation Глава 2. Установка

аппаратной части

2.1 The Front Panel Передняя панель

Figure 2-1 Рис. 2-1

The LEDs, locating on the front panel, indicates the device’s working status. For details, please

refer to LED Explanation. Светодиодные индикаторы, отображающие рабочее состояние

устройства, расположены на передней панели. Для более подробной информации, см.

таблицу Светодиодная индикация.

LED Explanation: Светодиодная индикация:

Name Status Indication

Power On Power is on.

Off Power is off.

ADSL On The LINE port is linked up.

Flash The ADSL negotiation is in progress.

Off The LINE port is linked down.

Internet On A successful PPP connection has been built.

Flash Data is being transferred over the Internet.

Off There is no successful PPP connection or the Router works on

Bridge mode.

WLAN On

The wireless function is enabled but no data is being transmitted.

Flash

There is wireless data being transmitted.

Off

The wireless function is disabled.

LAN On There is a successful connection on the LAN port but no activity.

Flash Data is being transferred over the LAN port.

Off There is no connection on the LAN port or the connection is

abnormal.
