TD-W8901G
54Mbps Wireless ADSL2+ Modem Router User Guide
Руководство пользователя: беспроводной
маршрутизатор 54Мбит/с с модемом ADSL2+
Кнопка BACK - возврат в предыдущее окно.
Click the CANCEL button to cancel the configuration which is made just now.
Кнопка CANCEL – отменить сделанные изменения.
4.4.3.3. IP Address Mapping Переадресация IP-адресов
Select Multiple for numbers of IPs in Figure Рис. 4 -41, and choose Advanced
Setup→NAT→IP Address Mapping(for Multiple IP Service)”. You can configure the Address
Mapping Rule in the next screen. The IP Address Mapping is for those VCs that configured with
multiple IPs. The IP Address Mapping rule is per-VC based (only for Multiple IPs' VCs).
В поле numbers of IPs укажите значение Multiple (Рис. 4-25) и выберитеAdvanced
Setup→NAT→IP Address Mapping(for Multiple IP Service)”. В появившемся окне можно
настроить правила переадресации адресов (Address Mapping Rule). Переадресация IP-
адресов предназначена для виртуальных соединений, имеющих несколько IP. Правило
переадресации IP-адресов зависит от виртуального соединения (только для виртуальных
соединений с несколькими IP).
Figure Рис. 4-44
Rule Index: Select the Virtual server rule index for this VC. You can specify 8 rules in
maximum. Rule Index: Выберите индекс правила Виртуального сервера для данного
виртуального соединения. Можно указать до 8 правил.
Rule Typ: There are four types: one-to-one, Many-to-One, Many-to-Many Overload and
Many-to-Many No-overload. Rule Typ: Существуют четыре типа правил: “One-to-one”,
“Many-to-One”, “Many-to-Many Overload” и “Many-to-Many No-overload”.
Local Start & End IP: Enter the local IP Address you plan to map to. Local Start IP is the
starting local IP address and Local End IP is the ending local IP address. If the rule is for all
local IPs, then the Start IP is 0.0.0.0 and the End IP is 255.255.255.255. Local Start & End
IP: Укажите локальный IP-адрес, для которого вы хотите установить переадресацию. В
57
