TD-W8901G
54Mbps Wireless ADSL2+ Modem Router User Guide
Руководство пользователя: беспроводной
маршрутизатор 54Мбит/с с модемом ADSL2+
правила фильтрации (представленного в списке Filter list).
IP/MAC Filter Listing: This displays the information about the MAC Filter rules.
IP/MAC Filter Listing: Здесь отображается информация по правилам фильтрации по
MAC-адресам.
To add a MAC Address filtering entry:
Создание правила фильтрации по MAC-адресам
For example: If you want to block the PCs with MAC addresses 00-0A-EB-00-07-BE and 00-0A-
EB-00-07-5F to access the Internet, you can configure as follows. Presume the rules are both
aimed at the interface PVC0, and their indexes are (1, 1) and (1, 2).
Например, нужно запретить выход в Интернет для компьютеров с MAC-адресами 00-0A-
EB-00-07-BE и 00-0A-EB-00-07-5F. Предположим, что правила направлены на интерфейс
PVC0 и их индексы будут (1, 1) и (1, 2).
Step 1: Select the “IP/MAC Filter” as the Filer Type Selection: Шаг 1: В поле Filer Type
Selection выберите значение “IP/MAC Filter”.
Select the “MAC” as the Rule Type on the Filter screen (show in Figure Рис. 4 -53).
В окне Filter в поле Rule Type укажите “MAC” (смотри Рис. 4-37).
,
Then you can configure the specific rule for the example.
После этого можно приступить к настройке правила для примера.
Step 2: Select the IP/MAC Filter Set Index and IP/MAC Filter Rule Index for the rule, then
select the Interface “PVC0”, and select the Direction “Outgoing” for the first rule. Шаг 2:
Выберите для правила значения параметров IP/MAC Filter Set Index и IP/MAC
Filter Rule Index. В поле Interface укажите “PVC0”, в поле Direction выберите
“Outgoing” (для первого правила).
77
