Instructions for the User
37
BURNER CONTROL KNOB
These knobs can be used to light the burners inside the barbecue.
To light the flame, proceed as described in point “9.4.1 Electronic burner
ignition”. Burners can also be lit by hand; see point “9.4.2 Manual burner ignition
(for internal burners only)” for further details.
RADIANT BURNER CONTROL KNOB
This knob can be used to light the radiant burner for use when cooking with the
rotisserie.
To light the flame, proceed as described in point “9.4.1 Electronic burner
ignition”.
AUXILIARY / RAPID BURNER CONTROL KNOB (model BQ6130T only)
These knobs can be used to light the Auxiliary or Rapid
side burners. These burners are useful for conventional
cooking or for keeping barbecued food hot.
To light the flame, proceed as described in point “9.4.1
Electronic burner ignition”.
SMOKER TRAY
The SMOKER tray is designed to give the meat special fragrances by using
pieces of aromatic wood, available from specialist outlets. When preparing
wood for this purpose, always follow the instructions provided on the pack.
This appliance is not fitted with a safety valve. It therefore must never be left unattended when in
operation. If you notice that the flames have gone out, turn the knobs to the OFF position AT ONCE and
wait a few minutes before attempting to ignite the burners again.
The lid must always be kept open while the burners are being lit. It can be lowered once they have
ignited and must be raised as soon as the thermometer fitted on it reaches 300°C. Take care not to
obstruct the combustion gas outlet flue in the back of the lid.
When the appliance is used for the first time, operate all the burners for 10 minutes with nothing on them
and with the lid open to burn off any oils and manufacturing residues.
WARNING: DO NOT LIGHT THE RADIANT BURNER WHEN THE BURNERS INSIDE THE
BARBECUE ARE IN OPERATION.
WARNING: TO PREVENT COMBUSTION OF RESIDUES FROM PREVIOUS USE OF THE
BARBECUE, CLEAN THE DRIPPING PAN, BURNER COMPARTMENT, CERAMIC PLATES AND
THE BURNERS THEMSELVES BEFORE EACH USE.
