![Smeg BQ61T [14/22] Using the barbecue](/views2/1018111/page14/bge.png)
Instructions for the User
38
9. USING THE BARBECUE
9.1 Fitting and changing the battery
Some models in this product range have a compartment to take one 1.5 V AA
PENCIL battery to supply the burner ignition plugs.
To fit or change the battery, follow the instructions provided below, referring to
the diagram:
• remove the dripping pan;
• access the battery compartment through the opening in the front panel
(see diagram);
• unscrew the cap A and remove the seal B;
• replace the battery C with another of the same type;
• take care that the battery poles correspond (see diagram on the right);
• replace the seal B and screw the cap A back on.
Caution: flat batteries must not be dumped at random or disposed of with other waste. They must be
collected separately and consigned to your local waste disposal company, or disposed of in the special
containers provided for old batteries.
9.2 Fitting and using the rotisserie motor
The rotisserie motor is supplied dismantled. To fit it, simply
screw the two screws (supplied) into the holes provided on
the right hand side of the barbecue.
Align the holes in the barbecue (A) with the holes in the
rotisserie motor (B). Then screw in the two screws to join
the two parts together. (See diagram on the right).
To use the rotisserie motor simply connect the plug to the
electrical mains and set the switch on I to turn it on. To
switch it off, simply return the switch to 0.
CAUTION: do not expose the rotisserie motor to bad weather as this might damage the device and
reduce its safety level. If necessary, remove the device from the barbecue by unscrewing its fixing
screws and store it in a place protected from the weather.
CAUTION, in case of damage to the rotisserie motor power supply cable, do not attempt to repair
or replace it yourself; contact an authorised service centre immediately.
Warning: disconnect the plug from the electrical mains before cleaning the rotisserie motor. Do not place
the rotisserie in water to clean it.
