Screen Setup
3
3 Screen Setup
3.13 Fine
Fine-adjust the screen to obtain a vivid picture.
This menu is available in Analog mode only.
The functions available on the monitor may vary depending on the model. Refer to the actual
product.
3.13.1 Adjusting Fine
1 When the Function Key Guide appears, select [ ] by moving the JOG button UP.
Next, press the JOG button.
2 Move to PICTURE controlling the JOG button UP/DOWN and press the JOG button.
3 Move to Fine controlling the JOG button UP/DOWN and press the JOG button.
The following screen will appear.
4 Adjust the Fine controlling the JOG button LEFT/RIGHT.
5 The selected option will be applied.
Faster
0
0
1344
0
Fine-tune the screen
to get a vivid picture.
Image Size
HDMI Black Level
Response Time
H-Position
V-Position
Coarse
Fine
Wide
