4. CONTENTS OF PACKAGE
4. Contents of package
Basic delivered set of router includes:
• router,
• power supply,
• crossover UTP cable,
• two external antennas,
• clip for the DIN rail,
• installation CD containing instructions,
• paper start guide.
Figure 1: Contents of package
Note: The router box and DIN mount are supplied in a metal case in the SL version.
The router can also be supplied as expansion accessories:
• One (Basic version) or two (Full version) expansion ports: RS232, RS485/422, MBUS,
ETHERNET, CNT, SWITCH, WIFI, WMBUS or SDH. Separation columns for mounting
expansion boards are included.
