5. ROUTER DESIGN
5.2 Delivery identification
Trade name Type name Other
CR10 v2B CR-10-v2 Basic version
CR10 v2B SL CR-10-v2 Basic version in the metal box
CR10 v2F CR-10-v2 Full version
CR10 v2F SL CR-10-v2 Full version in the metal box
Table 2: Delivery identification
Figure 6: Label CR10 v2B
Figure 7: Label CR10 v2B SL
Figure 8: Label CR10 v2F
Figure 9: Label CR10 v2F SL
