5. ROUTER DESIGN
5. Router design
5.1 Router versions
CR10 v2 router is supplied in the following versions:
Box SIM1 SIM2 I/O USB PORT1 PORT2 ETH
CR10 v2B Plastic
CR10 v2B SL Metal
CR10 v2F Plastic
CR10 v2F SL Metal
Table 1: Router versions
Figure 2: Front panel CR10 v2B
Figure 3: Front panel CR10 v2F
Figure 4: Front panel CR10 v2B SL
Figure 5: Front panel CR10 v2F SL
