TL-WPA4220/TL-WPA2220 300Mbps AV500/AV200 WiFi Powerline Extender

¾ Wireless - This field displays the current settings or information for wireless. They can be

configured on the Wireless → Wireless Settings page.

z Wireless Radio - Indicates whether the wireless radio feature of the powerline extender is

enabled or disabled.

z Name (SSID) - The SSID of the powerline extender.

z Channel - The wireless channel in use.

z Mode - The current wireless mode the powerline extender works on.

z Channel Width - The bandwidth of the wireless channel.

z MAC Address - The physical address of the powerline extender, as seen from the WLAN.

¾ System Up Time - This filed displays the length of the time since the powerline extender was last

powered on or reset.

Click the Refresh button to get the latest status and settings of the powerline extender.

3.3 Network

You can configure the IP parameters of the powerline extender on this page.

Figure 3-7 Network

¾ MAC Address - The physical address of the powerline extender's Ethernet port. The value can not

be changed.

¾ IP Address - Enter the IP address of the powerline extender in dotted-decimal notation (factory

default setting is 192.168.1.1).

¾ Subnet Mask - An address code that determines the size of the network. Usually it is

255.255.255.0.

Click the Save button to save your settings.

)

Note:

1. If you change the IP address, you must use the new IP address to log in to the powerline extender.

2. If the IP address of the powerline extender conflicts with other device in the intranet, a temporary IP

address will be generated at random.

3.4 Wireless

The Wireless option, improving functionality and performance for wireless network, can help you make
